Depending on their colors, most of those flashing lights are a good sign.
The front of a Netgear router, like many routers, is dotted with a wide range of lights and icons. Although some of the symbols like the power indicator are simple, the lights themselves can be much less clear. They often vary in color; sometimes they shine and other times they are solid. If you’ve never picked up the manual, deciphering what each of the many lights means doesn’t come naturally.
Understanding what each of the indicators on your Netgear router means is important for troubleshooting, as well as making sure everything is running as it should. Although some lights are usually more important than others, they all serve a purpose. Whether you have a standard router or one of the company’s mesh Wi-Fi systems, here’s how to better understand what your Netgear device is telling you.
The most important lights on your Netgear router
These are the lights on a router that are generally the most important to pay attention to, as they are indicators of the most influential statistics such as power and general internet connection status.
The power LED
Represented by the typical power symbol, this indicates information about your device’s firmware, as well as its power status. Not surprisingly, this is disabled when your router has no power.
- Solid green or white: The router is up and ready.
- Solid Amber: The router turns on.
- Flashing Amber: The router’s firmware is being upgraded, or you have pressed the reset button.
- Flashing white: The firmware of the router is damaged.
- Flashing white and amber: The router is in access point mode, which means it acts as a connection point for other devices instead of handling its normal router functions. Some functions such as VPN and remote management are not available.
If your router is not working properly, restart it first. In case it is completely unresponsive, you may need to do a factory reset.
Internet LED
The icon and light with a small circle showing a larger orbit shows your general connection status:
- Off: The router is not connected to a modem; check the Ethernet cable to make sure it is fully inserted and not damaged.
- Solid green or white: The internet connection is ready.
- Solid Amber: An Ethernet cable connection to the modem has been detected.
- Flashing white: The port sends and/or receives traffic.
WiFi LED
Represented by a small dot with two curves on each side, this indicator generally shows Wi-Fi traffic.
- Off: The router’s Wi-Fi radios are off.
- solid white: The router’s Wi-Fi radios are working.
- Flashing white: The router sends and/or receives Wi-Fi traffic.
Other lights on your Netgear router
Additional lights on your Netgear router are more useful for specific troubleshooting, or when plugging additional devices into the router.
Wi-Fi band LEDs
All modern routers should have lights for the 2.4GHz and 5GHz bands, as these have long been the standard. For a Wi-Fi 6E model or newer, you’ll also see a 6GHz light for the modern band. The lights differ depending on the bands currently in use, but the lights have the same meanings for each band.
- Off: This particular Wi-Fi radio is off.
- solid white: The Wi-Fi radio in question is working.
- Flashing white: The router sends and/or receives traffic via the corresponding Wi-Fi radio.
USB LEDs
Your router will have one of these lights for each USB port it contains, represented by the trident USB symbol or the text “USB 3.0.”
- Off: No USB device is connected to the port, or the Safely remove hardware Button was pressed and you are clear to remove the connected device.
- blink: A USB device is trying to connect.
- Solid green or white: A USB device is connected and ready to use.
Ethernet LEDs
These are labeled by numbers, with each representing an Ethernet port on the router. The color represents the speed of the connection: white or green for 1 Gbps connections, and amber for slower 100 Mbps or 10 Mbps Ethernet.
- Off: Nothing is connected to the port.
- Solid: A powered device is connected to the port.
- blink: The port sends and/or receives traffic.
WPS LED
Represented by what looks like a router with signals coming out, this light indicates the success of a WPS (Wi-Fi Protected Setup) connection, which allows you to add devices to your network without entering the network name and password. For the best router security, you should disable this.
- Off: No WPS connection.
- blink: A WPS connection is in progress.
- Solid: The WPS connection was successful.
Read the lights on a Netgear Orbi Mesh System
The lights on Netgear’s Orbi Wi-Fi mesh system are minimalist compared to a typical router, and represent key status slightly differently. There is a light on the bottom-front of the device, plus one on the back. The light in the front represents the connection status, while the one in the back is tied to the power and firmware of the device.
The front LED lights
- Solid blue light: The connection between the router and the satellite is strong.
- Solid amber light: The connection between the router and the satellite is OK, but not great.
- Solid Magenta Light: There is no backhaul connection or no internet connection.
- No light: Orbi does not gain power.
The rear LED light
- Solid green light: The router and the satellite are powered.
- Solid amber light: The device restarts.
- Pulsating Amber Light: The device updates its firmware or resets to factory settings.
- Pulsating red light: Possible hardware problems or connectivity errors.
- No light: Orbi does not gain power.
