Downsized gasoline engines and almost all diesels on sale rely on a turbocharger for the performance that once required a much larger engine, making a failed turbo one of the more expensive mistakes a driver can face. Knowing what is going wrong inside the unit, and what can be done about it, makes the decision easier when a garage provides the diagnosis.
Why are turbo failures so common on older cars?
Part of the answer lies in the age of the cars on British roads. According to the Society of Motor Manufacturers and Traders (SMMT), the number of cars in use will increase to 36.7 million in 2025, while their average age will increase to 9.7 years, from 9.5 years in 2024. Older cars with higher mileage are where turbochargers begin to show wear after years of heat cycles.
A turbo spins at extremely high speeds in the path of hot exhaust gas and depends on clean oil for lubrication and cooling. Most failures are traced back to oil contamination or starvation caused by a blocked feed line or excessive service. Foreign objects entering the intake or exhaust can also damage the compressor or turbine wheels.
Typical symptoms include a loss of power, blue or gray smoke from the exhaust, a screeching or siren-like noise under acceleration, rising oil consumption and a warning light on the dashboard.
What happens in a turbo rebuild?
A rebuild returns the original unit to working order by replacing the parts that wear while retaining the components that remain within tolerance.
Stripping and inspection
The technician completely disassembles the turbo, separates the compressor housing, turbine housing, and center section, then inspects each part for cracks, erosion, scoring, and heat damage. Badly cracked or warped housing usually precludes a reconstruction.
Clean up
Carbon deposits, oil sludge and dirt are removed from each component, typically with ultrasonic cleaning and blasting media appropriate for each material, so that faults hidden by dirt become visible.
Replace bearings, seals and CHRA
Bearings, thrust components, piston rings and seals are replaced as standard. Where the shaft or wheels are damaged, many specialists will fit a new center housing rotating assembly (CHRA), often called a cartridge. This core section includes the shaft, the wheels and the bearing system, so renewing it restores the heart of the turbo, while the original casing is reused.
Balancing and testing
The rotating assembly is balanced on special equipment at high speed, because even a small imbalance can quickly destroy new bearings. Variable-geometry turbos also need their vane mechanism set and calibrated so that boost is delivered correctly. And properly carried out turbo build up complete these checks before returning the unit to the customer.
How do the main repair options compare?
Drivers generally have five routes once a turbo has failed.
A reconstruction repairs the owner’s own unit and fits cases where the houses are healthy and the car can wait.
A reconditioned turbo went through a similar restoration process, but comes from existing stock rather than the owner’s car. It is usually more profitable than buying new.
An exchange unit is a ready-to-fit turbo that is supplied immediately, with the old unit returned as the core after the exchange was made. Its main appeal is speed, because the car is not waiting for its own part.
A new turbo is built entirely from fresh components, either from the original equipment manufacturer or from a quality aftermarket manufacturer. It has the highest price but removes any question about the history of the part.
The broad category of Replacement turbos covers any unit replaced by the one that failed, whether new, refurbished or refurbished, and is often the answer when the original is too badly damaged to save.
How should drivers choose between them?
The right option depends on the condition of the failed unit, the budget and how long the car can be off the road. A turbo specialist can review the failed unit and explain what options are realistic for it. Cracked housings point towards a replacement, while a turbo with worn bearings but healthy castings is well suited for a rebuild. Drivers who need their car back quickly often rely on an exchange.
Whichever route is taken, the cause of the original failure should be identified before a repaired or new unit is installed. Changing the oil and filter, cleaning or replacing the oil feed and return lines, and checking the intercooler for debris will all help prevent a repeat failure, as a restored turbo fitted to an engine with a restricted oil feed will fail again in the same manner.
A turbo failure is rarely welcome news, but it’s a well-understood fault with a number of sensible solutions, and a clear picture of each option will help drivers choose what’s right for their car and their circumstances.
